HE200VG Turbo 5326236 3786848H Turbocharger for Generator QSB Engine
| Place of Origin | China |
| Brand Name | Carrier |
| Certification | ISO 9001,IATF 16949 |
| Model Number | HE200VG Turbo |
HE200VG Turbo for QSB Engine
,Generator Turbocharger 5326236
,Turbocharger 3786848H for Generator
HE200VG Turbo 5326236 3786848H Turbocharger for Generator QSB Engine
Product Overview
High-Performance HE200VG Turbocharger for QSB Industrial Equipment
- Designed for QSB Engines: This HE200VG turbocharger is developed for selected QSB industrial diesel applications, including QSB 4.5L configurations. It helps restore the boost pressure and airflow needed for stable engine performance under changing loads.
- Variable Geometry Boost Control: The HE200VG uses variable geometry technology to adjust airflow according to engine speed and load. This helps improve low-speed response while maintaining the boost control needed during heavy-duty operation.
- Built for Industrial Work: QSB engines are used in equipment that may run for long periods under demanding conditions. This turbocharger is suitable for applications such as loaders, excavators, generator sets, pumps, compressors and agricultural machinery.
- Stable Response Under Load: The turbocharger is matched to the airflow requirements of the QSB engine platform. It supports smooth acceleration, consistent torque and reliable operation when the engine is powering hydraulic systems, PTO equipment or stationary industrial loads.
- Direct Replacement Configuration: The unit is manufactured for the listed applications, with the main mounting points, oil connections and air passages designed to match the original HE200VG configuration. Always compare the original turbocharger and engine details before ordering.
Technical Specifications & OEM Cross-Reference
| Turbo Model | HE200VG Turbo |
|---|---|
| Part Number | 5326236, 3786848H, 3798014, 5326235, 5326238, 5326244, 5326246, 5326254, 5326262H, 5328968, 5451865, 5502888, 5502901, 5502904, 5502905, 5502909, 5502912 |
| OE Number | 5502959, 5603941, 5603947, 5603955, 5603956, 5603957, 5604123, 5604127, 3798015, 5326259, 5326260, 5326262, 5326268, 5326270, 5326278, 5328971, 5353076 |
| Application | For Generator QSB Engine |
| Engine Model | QSB Engine |
| Brand | Carrier |
| Quality | 100% Tested High-Quality ISO 9001 & IATF 16949 certified |
| Type | K18 |
| Material | Alloy |
| Fuel | Diesel Engine |
Compatible OEM & Part Numbers
- Part Numbers: 5326236, 3786848H, 3798014, 5326235, 5326238, 5326244, 5326246, 5326254, 5326262H, 5328968, 5451865, 5502888, 5502901, 5502904, 5502905, 5502909, 5502912
- OEM Numbers: 5502959, 5603941, 5603947, 5603955, 5603956, 5603957, 5604123, 5604127, 3798015, 5326259, 5326260, 5326262, 5326268, 5326270, 5326278, 5328971, 5353076
Application
-
Industrial Engines: Selected QSB and QSB 4.5L industrial engine configurations
-
Construction Equipment: Skid-steer loaders, compact loaders, excavators, telehandlers and other off-highway machinery using compatible QSB engines
-
Agricultural Machinery: Tractors, harvesting equipment, irrigation power units and other agricultural equipment with matching engine specifications
-
Generator Sets: Industrial and standby generator sets using QSB engines for continuous or backup power generation
-
Pumps and Compressors: Water pumps, concrete pumps, air compressors and other stationary power units
-
Material-Handling Equipment: Forklifts, reach equipment and industrial vehicles using the listed HE200VG turbocharger configuration
-
Marine and Auxiliary Power: Selected marine auxiliary and workboat applications using compatible QSB engines
-
Typical Working Conditions: Construction sites, farms, quarries, industrial plants, power-generation facilities and other high-load environments
-
Fitment Note: QSB engines may use different turbochargers depending on engine rating, CPL, control system and equipment model. Confirm the original part number, actuator arrangement and turbocharger housing before purchase.
Q1: Does this HE200VG turbocharger fit all QSB engines?
No. The QSB engine family includes different displacements, power ratings and turbocharger configurations. This unit is intended for selected QSB applications using the listed HE200VG part numbers. Check the original turbocharger identification plate and engine CPL before ordering.
Q2: What is the relationship between 5326236 and 3786848H?
These are reference numbers commonly associated with the HE200VG turbocharger application. Other numbers in the list may represent production updates, service replacements or equipment-specific references. The original turbocharger number should always be matched before installation.
Q3: Does this turbocharger include the variable geometry actuator?
The exact actuator configuration depends on the product version. Before ordering, confirm whether the actuator is included and whether it matches the electrical connector and control system on your engine. If the original actuator is reused, it may require calibration after installation.
Q4: What should be checked before installing the replacement turbocharger?
Replace the engine oil and filter, inspect the oil feed and drain lines, clean the intake system and check the charge-air cooler for oil or debris. Make sure the variable geometry mechanism moves correctly, prime the turbocharger with clean engine oil and check all oil, air and exhaust connections after startup.
Q5: Do you provide worldwide shipping?What is the delivery timeframe?
We ship globally via premium carriers like DHL,FedEx,and UPS,as well as sea freight for bulk orders.In-stock items are typically dispatched within 24-48 hours. Express delivery to North America and Europe usually takes 5-7 business days.
About Us
Fengcheng Zhongke Turbocharger Co., Ltd. is a leading high-tech factory specializing in the R&D, production, and global distribution of high-performance turbochargers. Based in Fengcheng—one of the world’s most renowned turbocharger manufacturing hubs—we have grown from a local workshop into a global supplier, serving heavy-duty, commercial, and passenger vehicle markets worldwide.
At Zhongke, we don't just "make" parts.we engineer reliability.
- Material Integrity: We exclusively use K18 Nickel-Alloy turbine wheels, capable of withstanding extreme exhaust temperatures (up to 950°C) without deformation.
- Dynamic Balancing: 100% of our turbochargers undergo high-speed dynamic balancing tests at 150,000+ RPM to guarantee zero vibration and extended bearing life.
- Certified Quality: Our production processes are certified under ISO 9001 and IATF 16949, the gold standards for the global automotive and heavy-machinery industries.
Manufacturing Prowess:Our facility is equipped with state-of-the-art production lines, including precision 5-Axis CNC machining centers, high-speed VSR (Vibration Sorting Rig) balancing machines, and advanced material testing labs.
Our Specialization:We maintain a vast inventory of over 3,500+ turbocharger models, with a focus on heavy-duty and construction machinery engines. Focused on optimizing fuel efficiency and restoring factory horsepower, our passenger car turbos are engineered with the same precision and K18 heat-resistant materials as our industrial line, ensuring reliable performance for daily commuting and high-speed driving alike.
Global Partnership & Support: Zhongke Turbo is more than just a manufacturer; we are your long-term technical partner. With nearly 30 years of export experience, we understand the logistics and technical requirements of the international market. We provide a warranty and dedicated technical support to help our partners succeed.
- Key Export Regions: North America, Europe, the Middle East, Africa, Latin America, and Southeast Asia.
Experience the difference of nearly 30 years of factory expertise. Contact us today for wholesale inquiries or technical consultations.
